Solar Film Temperature Meter Insulation Film Glass Temperature Tester LS300 Solar Tester Thermal Insulation Temperature Testing Device, AC220V Single-Phase

Product Parameters Voltage: AC220V, single-phase Power: 400W Operating current: 2A Accuracy: ±0.5℃ Left-right temperature non-uniformity: 2℃ Temperature measuring range: -55℃ ~ +125℃ Time for temperature test: 1 min Size of the testing glass: 7.9"*6.3"(20×16cm) Tester size: 13.6*7.9*16.1" (34.5×20×41cm) Package size: 18.9*15.7*11.0" (48×40×28cm) Net weight/Gross weight: 20.9lbs(9.5kg) / 23.6lbs(10.7kg) Operation instructure: There are three testing statuses of the meter: Waiting for testing, Testing in progress, and Test completed. - Waiting for testing: The "Temperature difference" data is zero and flashes to indicate waiting for testing. Under this status, Press the "Reset/test" button to start testing. - Testing in progress: The "Temperature difference" data stops flashing, and the infrared lamps are lit up. After the 1-min test ends, the infrared lamps are turned off and the instrument automatically enters into the status of end of testing. - Test completed: Temperature values are held. Press "Reset/test" to release the data-hold and enter into the status of waiting for testing.

• Simple Control Panel: The insulation film glass temperature tester uses LED digital tube display panel, which can visually display the "temperature difference" and "temperature", simple operation and clear reading, besides, the design of two test spaces can directly compare the thermal insulation effect of two different materials side by side, time and effort saving
• Precise Testing Accuracy: The solar film temperature meter uses high-precision temperature sensor and infrared lamp to accurately evaluate the thermal insulation performance of solar film, efficient and accurate heating, which can ensure the accuracy and reliability of the test results
• Real-Time Temperature Capture: Each space is equipped with a high-precision temperature sensor, which can accurately measure the temperature of the test area and capture the temperature change in real time to ensure the accuracy of the test data
• Wide Application Scope: The thermal insulation film temperature testing device enables side-by-side comparison of the thermal insulation performance of two different materials, displaying the temperature difference before and after testing, so that it's a specialized instrument used to demonstrate the insulation effectiveness of materials like automotive films, insulated glass, and thermal coatings
• Simlple Structure: There are two cooling fans installed on the machine back, to quickly cool down and ensure the stable testing operation for a long time, they also protect equipment and test samples for extended use, and the tester is easily carried to the desired location with a handle on the top
